Pneumatic Bulk Loading Machine for Powder Materials

I. Overview

SZ Type Cement Bulk Loader is used for bulk loading of cement, fly ash, mineral powder and other powdery materials in cement plants, building materials, metallurgy, coal and grain industries. It connects the silo to the truck/train and realizes automatic bulk loading.SZ

II. Working Principle

The machine uses airslide conveying to discharge materials. The loading head extends to the tank mouth, and materials flow into the truck under gravity and aeration. Dust is collected by the dust removal system to realize closed and clean bulk loading.

III. Features & Advantages

1. High Loading Efficiency: Capacity of 60–300 t/h; fast and stable operation.
2. Flexible Structure: Available in various configurations, including silo-bottom and silo-side mounting types.
3. Automatic Lifting: The loading head lifts smoothly and safely.
4. Dust-Free & Eco-Friendly: Equipped with a dust removal interface to prevent spillage.
5. Reliable Pneumatic System: Ensures stable control and a long service life.
6. Easy Installation & Operation

IV. Application

• Cement plants: cement bulk loading
• Building materials: fly ash, slag powder, limestone powder
• Port & logistics: bulk powder truck loading
• Silo discharge & bulk transport systems

V. Selection Guide

1. Loading capacity required (t/h)
2. Installation type: silo bottom / silo side
3. Lifting distance and installation space
4. Matching dust removal system
5. Vehicle type: truck / train
